5T Pharmaceutical Granulator Machine Tapioca Starch Dry Granulation Of Tablets

Brand Name : SENMAO

Model Number : L

Certification : CE, ISO 9001: 2008, ISO 10004

Place of Origin : China

MOQ : 1set

Price : 36,000 USD to 143,000 USD

Payment Terms : L/C , D/A , D/P , T/T , Western Union , MoneyGram

Supply Ability : 30Sets/Months

Delivery Time : 7-15Working Days

Packaging Details : Wooden Case + Plastic Film

Type : Roller Compactor Granulation

Application : Medicine Processing, Chemicals Processing, Plastics

Condition : New

Brand name : Senmao

Voltage : customize

Power(kw) : 22

Dimension(L*W*H) : variable

Key Selling Points : Roller granulation

Warranty : 1years

Weight(Ton) : 5

Applicable Industries : Pero-chemical industry,fine-chemical industry,etc

Machinery Test Report : Provided

Video outging inspection : Provided

warranty to core components : 1Year

Mateial : SUS304,SUS316L

Product Name : SZG series conical vacuum dryer

Delivery : 45-90days

Guarantee period : 1year

Package : wooden case

Contact Now

products descriptions
Dry granulation is transforming the powder to granules via compacting (to flake), breaking, granulating and sifting, the powder needs to be less than 10% moisture content. After compaction, density of raw material could be 1.5-3times heavier with certain strength.


products Principle
The raw material is fed from top of granulator, after degas, forced feeder transport the raw material into feeding port of two compactors, The two roller presses rotate at the same speed in opposite directions,raw material is forced compacted to flake shape by high pressure, and will drop out of compactors by it’s gravity. The flake product then enter breaker and granulator to get dispersed and then enter sifter to get classified. Qualified granule product is transferred to storage silo or directly get packed, unqualified product is re-cycled back to forced feeder to get compacted again. Compacting pressure is generated by hydraulic pressure system, and it is available to be adjusted. There are several kinds of product shape are available for choice by replacing compacting roller surface, such as flake shape, irregular shape, strip shape, olive shape and oblate spheroid shape


products parameters

型号 LS-1 Ls-2 Ls-3 Ls-4 Ls-5
压辊直径 120X35 180X60 240X100 300X120 360X180
生产能力 1~30 50~150 100~300 150~500 200~800
成品粒径 0.2~2 0.2~2 0.2~2 0.2~2 0.2~2
成型压力 0~25MP 0~25MP 0~25MP 0~25MP 0~25MP
功率 4 10 15 20 38
外形尺寸 1000X1200X1700 1200x1400x1800 1400x1600x1900 1600x1800x1950 2000x2200x1920
重量 0.8 1.8 2.5 3 4.2


Details Image​

5T Pharmaceutical Granulator Machine Tapioca Starch Dry Granulation Of Tablets
